Railway Systems
Description
GRP Railway Systems
A comprehensive range of rapid fit, durable solutions for improvement & refurbishment across the railway infrastructure.
Meeting the varied demands placed from many parts of the railway infrastructure is a significant sector of our business.
Products and materials need to be carefully designed & selected to offer safety, durability, long life and cost efficiency.
Factors influencing the procurement process will likely include:
safety critical applications, special wear & loading characteristics, resistance to extreme climatic conditions, maintenance requirements etc.
Composites
Composite materials are now a common choice to meet or exceed these criteria and by virtue of their physical & mechanical properties, represent an excellent investment with low lifecycle costs and long term value.
Working closely with designers, engineers and contractors alike, Evergrip offer a wide variety of high quality GRP solutions to fit these requirements. Our products are designed and installed to comply with all relevant BS & EN codes including BS 4592.
• Platform decking, repair products & substructures
• Stair treads
• Hand rail systems
• Surface mounted tactile paving
• Anti-slip walkway surfaces
• Facilities/inspection/maintenance access platforms
• Platform access ramps
• Staircases & gates
• Catchpit covers
• Ballast panels / boards
• Infill panels
• Trench/trough covers
1. GRP Pedestrian Crossing
2. GRP Service Platforms
3. Further GRP Railway Applications
| ITEM | HIGHT (MM) |
BEARING BAR THICKNESS(TOP/BOTTOM) | MESH SIZE (MM) |
STANDARD PANEL SIZE AVAILABLE(MM) | APPROX.WEIGHT (KG/M²) |
OPENRATE(%) |
| 1 | 13MM | 6.0/5.0 | 38x38MM | 1220×4000 | 6.0 | 68% |
| 1220×3660 | ||||||
| 2 | 12MM | 6.0/5.0 | 50x50MM | 1906×4012 | 4.8 | 82% |
| 3 | 13MM | 6.0/5.0 | 50X50MM DIAMOND |
1215×4115 | 6.0 | 82% |
| 4 | 25MM | 6.5/5.0 | 83x83MM | 1007×4007 | 5.8 | 84% |
| 5 | 40MM | 7.0/5.0 | 83x83MM | 1007×4007 | 9.5 | 84% |
| 1507×4088 |
